Introduction

Holy fuck, I lost basic, very, very much!

Where to practice

Kodekloud Lab

IO Redirection

I think this is the most command I often used but never understand correctly, LOL. Yes, it is 2>&1. But no more, today I swear I will remember and understand it! So let's take an example:

./script.sh > output.txt 2>&1

./script.sh will give to output

bob@ubuntu-host ~ ✖ ./script.sh
/home/bob
./script.sh: line 2: lss: command not found

This part > output.txt: can be understood as redirect stdout (file descriptor 1) into file output.txt

This part 2>&1: can be understood as redirect stderr (file descriptor 2) into file descriptor 1 pointed to. At this time file descriptor 1 already getting redirected into output.txt, so file descriptor 2 will go together xD

And order is important

It must be > output.txt 2>&1. Example:

bob@ubuntu-host ~ ➜  ./script.sh > output.txt 2>&1

bob@ubuntu-host ~ ✖ cat output.txt
/home/bob
./script.sh: line 2: lss: command not found

If 2>&1 > asd.txt: only stdout getting into file. Example:

bob@ubuntu-host ~ ➜  ./script.sh 2>&1 > asd.txt
./script.sh: line 2: lss: command not found

bob@ubuntu-host ~ ✖ cat asd.txt
/home/bob

Shell Redirection Cheat sheet:

> file 2>&1 Redirects both stdout and stderr to a file (the most standard/compatible method).
&> file Shorthand for the above (supported in bash and zsh).
>> file 2>&1 Appends both stdout and stderr to a file.
2>/dev/null Discards error messages (stderr); keeps only the standard output.

Redirection Use Cases:

./script.sh > output.txt 2>&1 Captures everything (logs + errors) into a single file.
./script.sh > /dev/null 2>&1 Total silence; suppresses all output and error messages completely.
./script.sh 2> error.txt Redirects only the errors to a file; the normal logs will still show up on your terminal.

And the last, we had fd2/fd1 so what is fd0? It is standard input (stdin). Example: mysql database_name < backup.sql

LVM (Logical Volume Manager)

To be honest, I rarely use LVM in OpenStack environments because my managed platforms are Elasticsearch, Kafka, which all support multiple disks. You know in the OpenStack environment, 1 volume 10 GB has 200 IOPS, but 2 volumes 5 GB have 400 IOPS. Same size but double IOPS, that is why I used multi disk.

But when it comes to MongoDB, it needs to use LVM since MongoDB doesn't support multi-disk. But It was a lab setup without document write back, so it is like fire and forget mode -.-

So that is a story for simple knowledge everyone remembers and understands, but not me xD. So this is "day one" instead of "one day"!

Physical Volume (PV)

They are physical volumes (P) like /dev/sdb or disk partition /dev/sda1 you want to put it in LVM system.

Init PV: pvcreate /dev/sdb (turn /dev/sdb into material for LVM)
Check PV: pvdisplay or pvs

Example:

### PV Create
root@caleston-lp10 ~ ➜  pvcreate /dev/vdb /dev/vdc
  Physical volume "/dev/vdb" successfully created.
  Physical volume "/dev/vdc" successfully created.
### PV Display
root@caleston-lp10 ~ ➜  pvdisplay
  "/dev/vdb" is a new physical volume of "1.00 GiB"
  --- NEW Physical volume ---
  PV Name               /dev/vdb
  VG Name
  PV Size               1.00 GiB
  Allocatable           NO
  PE Size               0
  Total PE              0
  Free PE               0
  Allocated PE          0
  PV UUID               aaPJMu-vtoq-yU0a-xsg4-LwPV-IYE4-TRb1sF

  "/dev/vdc" is a new physical volume of "1.00 GiB"
  --- NEW Physical volume ---
  PV Name               /dev/vdc
  VG Name
  PV Size               1.00 GiB
  Allocatable           NO
  PE Size               0
  Total PE              0
  Free PE               0
  Allocated PE          0
  PV UUID               y1Mod8-Li2M-i7NR-Yqg4-mjZt-gEos-M4EwSe


root@caleston-lp10 ~ ➜  pvs
  PV         VG Fmt  Attr PSize PFree
  /dev/vdb      lvm2 ---  1.00g 1.00g
  /dev/vdc      lvm2 ---  1.00g 1.00g

Remove PV from LVM: pvremove /dev/vdc

root@caleston-lp10 ~ ➜  pvremove /dev/vdc
  Labels on physical volume "/dev/vdc" successfully wiped.

root@caleston-lp10 ~ ➜  pvs
  PV         VG Fmt  Attr PSize PFree
  /dev/vdb      lvm2 ---  1.00g 1.00g

Volume Group (VG)

Group of physical volumes (V). You group all the PVs together into one large group called VGs.

VG named by you, ex: VG named "my-vg"

Command to create VG: vgcreate volume-name pv-here

root@caleston-lp10 ~ ➜  vgcreate volume1 /dev/vdb
  Volume group "volume1" successfully created

Command to check VG: vgdisplay or vgs

Extend VG by adding PV: vgextend volume-name pv-here

root@caleston-lp10 ~ ➜  vgextend volume1 /dev/vdc
  Physical volume "/dev/vdc" successfully created.
  Volume group "volume1" successfully extended

# Before add pv /dev/vdc to vg volume1, it was 1 PV and Vsize 1.00g
root@caleston-lp10 ~ ➜  vgs
  VG      #PV #LV #SN Attr   VSize VFree
  volume1   2   0   0 wz--n- 1.99g 1.99g

Remove PV from VG: vgreduce volume-name pv-here

root@caleston-lp10 ~ ➜  vgreduce volume1 /dev/vdc
  Removed "/dev/vdc" from volume group "volume1"

root@caleston-lp10 ~ ➜  vgs
  VG      #PV #LV #SN Attr   VSize    VFree
  volume1   1   0   0 wz--n- 1020.00m 1020.00m

Logical Volume (LV)

from big VG, you divide it into smaller or all to use called LV (L).

Relationship: 1 VG can divide into 1 or more LV

Init command: Create LV named smalldata, size 0.5 G from VG volume1.

root@caleston-lp10 ~ ✖ lvcreate -L 0.5G -n smalldata volume1
  Logical volume "smalldata" created.
root@caleston-lp10 ~ ➜  lvs
  LV        VG      Attr       LSize   Pool Origin Data%  Meta%  Move Log Cpy%Sync Convert
  smalldata volume1 -wi-a----- 512.00m

Display LV command: lvs or lvdisplay

Resize LV to 752 MB: param can be -L or --size xD

root@caleston-lp10 ~ ✖ lvresize -L 752M volume1/smalldata
  Size of logical volume volume1/smalldata changed from 512.00 MiB (128 extents) to 752.00 MiB (188 extents).
  Logical volume volume1/smalldata successfully resized.

root@caleston-lp10 ~ ➜  lvresize --size 753M volume1/smalldata
  Rounding size to boundary between physical extents: 756.00 MiB.
  Size of logical volume volume1/smalldata changed from 752.00 MiB (188 extents) to 756.00 MiB (189 extents).
  Logical volume volume1/smalldata successfully resized.

While lvresize can reduce size of LV, lvextend can not

lvextend -l +100%FREE /dev/VG1/LV1 # Add 100% free of VG1 to LV1
lvextend -L 5G /dev/VG1/LV1 # Add LV1 Size to 5Gb, error if current size > 5G

lvextend -l +100%FREE -r /dev/VG1/LV1  # -r auto resize fs

Destroy/Remove LV from VG

root@caleston-lp10 ~ ➜  lvremove volume1/smalldata
Do you really want to remove and DISCARD active logical volume volume1/smalldata? [y/n]: y
  Logical volume "smalldata" successfully removed
  root@caleston-lp10 ~ ➜  vgs
  VG      #PV #LV #SN Attr   VSize    VFree
  volume1   1   0   0 wz--n- 1020.00m 1020.00m

root@caleston-lp10 ~ ➜  lvs

Create filesystem from LV

XFS or EXT4, your choice

Command: mkfs.xfs /dev/volume1/smalldata

mkfs.xfs /dev/volume1/smalldata

Advanced Permissions

Get ACL

Question: Check permission for user john in file archive

root@caleston-lp10 ~ ➜  ls -lia
total 44
1572865 drwx------.  7 root root 4096 Dec 29 05:16 .
      2 drwxr-xr-x. 19 root root 4096 Sep 19  2024 ..
1572885 -rw-r--r--+  1 root root    0 Dec 29 05:16 archive

We already know others only has read permission, and john is in others. There is another way give same output

root@caleston-lp10 ~ ➜  getfacl archive
# file: archive
# owner: root
# group: root
user::rw-
user:john:r--
group::r--
mask::r--
other::r--

Set ACL

We have this file specialfile, we want to add john can read and write it

root@caleston-lp10 ~ ✖ getfacl specialfile
# file: specialfile
# owner: root
# group: root
user::rw-
group::r--
other::r--
###
root@caleston-lp10 ~ ➜  setfacl --modify user:john:rw specialfile  # Alternative: setfacl -m u:john:rw specialfile
root@caleston-lp10 ~ ➜  getfacl specialfile |grep john
user:john:rw-
### For group mail and permission read and execute
root@caleston-lp10 ~ ➜  setfacl --modify group:mail:rx specialfile
### For recursive within folder
setfacl --recursive --modify user:john:rwx collection/

Remove ACL

root@caleston-lp10 ~ ✖ setfacl --remove user:john specialfile

root@caleston-lp10 ~ ➜  getfacl specialfile |grep john

Create Raid 1

Question: Create Raid 1 named /dev/md0 with 2 disk /dev/vdb /dev/vdc

root@caleston-lp10 ~ ➜  mdadm --create /dev/md0 --level=1 --raid-devices=2 /dev/vdb /dev/vdc
mdadm: Note: this array has metadata at the start and
    may not be suitable as a boot device.  If you plan to
    store '/boot' on this device please ensure that
    your boot-loader understands md/v1.x metadata, or use
    --metadata=0.90
Continue creating array?
Continue creating array? (y/n) y
mdadm: Defaulting to version 1.2 metadata
mdadm: array /dev/md0 started.

Special Bits

Haha, I still don't remember this enough like common permission. I guess I rarely use it. So this is a chance for me, to write a document, whenever I forget, I read this document again!

SetUID (Set User ID): 4

So when execute a binary that have this bit, anyone executes that file will has permission like owner of file (permission borrow?)

Example: passwd Symbol: rwsr-xr-x ==> 4755

ll /usr/bin/passwd
-rwsr-xr-x. 1 root root 59976 Feb  6  2024 /usr/bin/passwd*

If owner doesn't have executes:

# ll
-rw-rw-r--. 1 bob  bob     0 Dec 29 07:47 test.txt
# chmod 4644 test.txt && ll
-rwSr--r--. 1 bob  bob     0 Dec 29 07:47 test.txt

SetGID (Set Group ID): 2

This is more interesting, especially when applied to directories.

On a file: When you run the file, it runs with the group permissions of the file’s group owner (you "borrow" the group’s rights).
On a directory (this is the most common and useful case):
Any file or subdirectory created inside this folder will automatically inherit the group owner of the parent directory — instead of taking the group of the user who created it.

Real benefit: In team shared folders, this ensures everyone in the same group can read, write, and manage each other’s files without needing to manually change ownership every time.

Sticky Bit: 1

This commonly used by directory to protect file getting deleted.

Mechanic: If folder has stick bit set, only owner or root has permission to delete/rename/... that file.

Example: /tmp folder, Everyone can create file in that, but you can not delete file of other user

Symbol: t in the last (rwxrwxrwt)

drwxrwxrwt.  11 root root       4096 Dec 29 07:48 tmp/

Security Limit / Resource Limit

Haha, I often used for increase max open file of mysql server instance. Read /etc/security/limits.conf

Scenario: Set limit for user john that he can open no more than 30 process. Set limit for user jane that she can not create file more than 1024kb, soft limit

john hard nproc 30
jane soft fsize 1024

Fallocate and Swap

For the exam....

fallocate -l 1024M /swfile # Locate file
chmod 600 /swfile # Change permission
mkswap /swfile # Create swap
swapon /swfile # Enable swap
/swfile none swap sw 0 0 # mount on boot in /etc/fstab

Manage Virtual Machines (libvirt)

Shiet, I have no fucking idea about this!!!!

Question:

For the operating system information parameter use the ubuntu22.04.
Name the virtual machine mockexam2.
Assign 1024 MB of RAM to this machine.
Assign it one virtual CPU.
Import the disk image /var/lib/libvirt/images/ubuntu.img to this virtual machine.
At the end of your command, you can add the parameter --noautoconsole to avoid waiting for this virtual machine to boot up, and not get stuck in the virtual console after it initializes.

Answer copied:

# Install
sudo virt-install \
  --name mockexam2 \
  --memory 1024 \
  --vcpus 1 \
  --os-variant ubuntu22.04 \
  --disk path=/var/lib/libvirt/images/ubuntu.img \
  --import \
  --noautoconsole
# Auto start
sudo virsh autostart mockexam2

Check:

root@caleston-lp10 ~ ➜  virsh list --all
 Id   Name        State
---------------------------
 1    mockexam2   running

Create new VM with New Disk:

sudo virt-install \
  --name myvm \
  --memory 2048 \
  --vcpus 2 \
  --os-variant ubuntu22.04 \
  --disk size=20 \
  --cdrom /path/to/ubuntu.iso \
  --network network=default \
  --graphics vnc \
  --noautoconsole

Others

Find process eating high IO

First find process first: iotop or pidstat -d 1

SELinux

Get current SELinux mode: getenforce or more detail with sestatus

sestatus
SELinux status:                 enabled
SELinuxfs mount:                /sys/fs/selinux
SELinux root directory:         /etc/selinux
Loaded policy name:             default
Current mode:                   permissive
Mode from config file:          permissive
Policy MLS status:              enabled
Policy deny_unknown status:     allowed
Memory protection checking:     requested (insecure)
Max kernel policy version:      33

Check if file that has the wrong SELinux type label:

ls -Z /usr/bin/less
system_u:object_r:user_tmp_t:s0 /usr/bin/less

Fix:

root@node01 ~ ➜ restorecon -v /usr/bin/less
root@node01 ~ ➜  ls -Z /usr/bin/less
system_u:object_r:bin_t:s0 /usr/bin/less

Create bridge network

Question: have 2 interfaces eth1 and eth2,turn DHCP off

Answer: edit file /etc/netplan/60-bridge.yaml

network:
  version: 2
  ethernets:
    eth1:
      dhcp4: no
    eth2:
      dhcp4: no
  bridges:
    bridge1:
      interfaces: [eth1, eth2]
      dhcp4: yes

Run command: netplan apply Check:

root@node01 ~ ➜  ip addr show bridge1
6: bridge1: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default qlen 1000
    link/ether 22:17:8b:bb:af:16 brd ff:ff:ff:ff:ff:ff
    inet 172.28.128.239/24 metric 100 brd 172.28.128.255 scope global dynamic bridge1
       valid_lft 3585sec preferred_lft 3585sec
    inet6 fe80::2017:8bff:febb:af16/64 scope link
       valid_lft forever preferred_lft forever
root@node01 ~ ➜  bridge link show
3: eth1: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 master bridge1 state forwarding priority 32 cost 100
4: eth2: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 master bridge1 state forwarding priority 32 cost 100

For Exam: man netplan

Iptables

Redirect rule: redirects any IPv4 packet from the 10.5.5.0/24 CIDR range incoming on port 81 to another machine with the IP address 192.168.5.2 on port 80.

sudo iptables -t nat -A PREROUTING -p tcp -s 10.5.5.0/24 --dport 81 -j DNAT --to-destination 192.168.5.2:80

masquerading rule so that packets redirected from 10.5.5.0/24 have a way of getting back to that sender

sudo iptables -t nat -A POSTROUTING -s 10.5.5.0/24 -j MASQUERADE

Make it persistent:

sudo apt install iptables-persistent

OpenSSL Cheat Sheet for LFCS

Generate Private Key

openssl genrsa -out server.key 2048

Generate CSR (Certificate Signing Request)

openssl req -new -key server.key -out server.csr

Generate Self-signed Cert (single command)

openssl req -x509 -nodes -days 365 -newkey rsa:2048 -keyout server.key -out server.crt

View Information

# View cert
openssl x509 -in server.crt -noout -text
openssl x509 -in server.crt -noout -subject
openssl x509 -in server.crt -noout -dates

# View CSR
openssl req -in server.csr -noout -text

# View private key
openssl rsa -in server.key -check

Verify cert and key match

openssl x509 -in server.crt -noout -modulus | md5sum
openssl rsa -in server.key -noout -modulus | md5sum
# Both must be identical

Quick Reference

Task	Keyword
Generate key	`genrsa`
Generate CSR	`req -new`
Generate self-signed	`req -x509`
View cert	`x509 -in`
View CSR	`req -in`

Basic Flow

genrsa → req -new → CA sign → .crt

Or shortcut: req -x509 -newkey (generate key + cert at once)

Conclusion

This exam is considered easy to pass because it requires only 67 to pass! In fact, I only spent 2 days preparing.

Passing this exam doesn't make me satisfied, I am satisfied with the progress, what I learned and remembered while preparing for this exam!

Scored 86/100, not too bad! Hats off to people who scored 100/100, since there are some questions that are really advanced and require deep knowledge to score!

Thanks to KodeKloud for providing good mock exams!

Prepare for Linux Foundation Certified System Administrator (LFCS)
