OpenTelemetry Certified Associate (OTCA) overview

1. Observability Fundamentals

Understanding the "Why" before the "How."

• The Three Pillars: Deep dive into Traces, Metrics, and Logs.
• The Need for OpenTelemetry: Solving "Vendor Lock-in" and standardizing telemetry data collection.
• Monitoring vs. Observability: Understanding the difference between knowing "what" is happening vs. "why" it is happening.

2. OpenTelemetry Core Architecture

The backbone of the project.

• The OTel Collector: Understanding the data pipeline: Receivers (ingestion), Processors (transformation), and Exporters (destination).
• OTLP (OpenTelemetry Protocol): The unified protocol for delivering telemetry data.
• Context Propagation: How OTel maintains the "trace context" as requests move across different microservices (Baggage and Traceparent).

Example for Context Propagation:

Request to service A
├─ Span A (trace_id: 123, span_id: A1, parent: null)
   ├─ Span B - call service B (trace_id: 123, span_id: B1, parent: A1)
   │  └─ Span C - query DB (trace_id: 123, span_id: C1, parent: B1)
   └─ Span D - call service C (trace_id: 123, span_id: D1, parent: A1)

3. OpenTelemetry Specification

Key concepts and data models.

• Resources: Metadata describing the entity producing the telemetry (e.g., service.name, host.id).
• Traces & Spans: Understanding Span hierarchy, Span Events, and Span Attributes.
• Metrics: Learning about different instrument types: Counter, UpDownCounter, Histogram, and Gauge.
• Logs: How OTel bridges the gap with legacy logging systems.

4. Instrumentation Approaches

How to get data out of your applications.

• Automatic Instrumentation: Using Agents or SDKs to collect data without changing the application code (Zero-code approach).
• Manual Instrumentation: Using the OpenTelemetry API and SDK to manually define custom spans and metrics within the business logic.
• API vs. SDK: Understanding the distinction (API is for instrumentation; SDK is for configuration and processing).

5. Configuration & Deployment Patterns

Putting OTel into production.

• Deployment Modes: Difference between running the Collector as an Agent (Sidecar/DaemonSet) vs. a Gateway (Standalone service).
• Collector Configuration: Mastering the YAML structure (extensions, receivers, processors, exporters, and service pipelines).
• Sampling: Understanding Head-based sampling vs. Tail-based sampling to manage data volume and costs.

6. Ecosystem & Interoperability

• CNCF Landscape: OpenTelemetry’s role as a CNCF incubated project.
• Compatibility: How OTel interacts with other tools like Prometheus, Jaeger, Zipkin, and Fluentd.
• Semantic Conventions: The importance of standardized naming for attributes across different technologies.

Sections That Need to Be Understood

1. Context Propagation (The "Glue" of Tracing)

Domain: OpenTelemetry API and SDK

Distributed tracing cannot work without Context Propagation. This is the mechanism that transfers metadata (Trace ID, Span ID) from service A to service B to connect spans into a complete trace.

• Trace Context (W3C Standard): OpenTelemetry uses the W3C traceparent header standard to transmit information.
  • Format: version-traceid-parentid-traceflags
  • Example: 00-4bf92f3577b34da6a3ce929d0e0e4736-00f067aa0ba902b7-01
• Baggage: Used to transmit custom key-value pairs (like userid=123, env=prod) throughout services without creating new spans. This data can be used for filtering or sampling in later steps.
• Propagators: Objects responsible for injecting (attaching to request) and extracting (retrieving from request) context.

References:

• OTel Docs: Context Propagation
• W3C Trace Context Specification

2. OTel Metrics Instruments (vs. Prometheus)

Domain: OpenTelemetry API and SDK

Unlike Prometheus which has only 4 basic metric types, OpenTelemetry divides them further to map accurately to various backends. It is crucial to distinguish when to use which.

• Synchronous Instruments (Called by user when event occurs):
  • Counter: Only increases (Monotonic). Example: http_requests_total.
  • UpDownCounter: Increases or decreases. Example: queue_size (similar to Prometheus Gauge).
  • Histogram: Records value distribution. Example: http_response_time.
• Asynchronous Instruments (Observer - Only collected when invoked):
  • ObservableCounter, ObservableUpDownCounter, ObservableGauge: Used to read values from the system (like CPU usage, Memory usage) periodically (scrape interval) instead of per request.

Note: OTel does NOT have Summary type. Summary is Prometheus-specific. OTel uses Histogram with explicit buckets or exponential histograms instead.

References:

• OTel Docs: Metrics Concepts
• OTel Specification: Metrics Data Model

3. Sampling Strategies (Head vs. Tail)

Domain: The OpenTelemetry Collector & API/SDK

To save storage costs and bandwidth, we cannot store 100% of traces. Sampling is the technique to decide whether to keep or drop a trace.

• Head Sampling (At SDK/Client): Decided immediately when the trace starts (root span).
  • Pros: Saves the most resources as dropped traces are not processed further.
  • Cons: May miss critical error traces (since errors are unknown at the start).
  • Strategies: ParentBased (follows parent), TraceIDRatioBased (% ratio), AlwaysOn, AlwaysOff.
• Tail Sampling (At Collector): Decided after the trace is complete (or mostly complete).
  • Pros: Keeps exactly the interesting traces (High Latency, Status code = 500).
  • Cons: Consumes RAM/CPU at the Collector as it must temporarily store all spans before deciding.

References:

• OTel Docs: Sampling
• Tail Sampling Processor (Collector Contrib)

4. Collector Deployment Patterns

Domain: The OpenTelemetry Collector

The Collector is the "heart" of the OTel architecture. There are 3 main deployment models to master for the exam:

1. Agent (Sidecar/DaemonSet): Runs right next to the application (on the same Pod or Node).
   • Role: Receives data from App -> Adds metadata (k8s pod name, host ip) -> Sends to Gateway. Helps reduce connection management load for the App.
2. Gateway (Standalone Service): An independent Collector cluster (Deployment).
   • Role: Receives data from Agent -> Heavy processing (Tail Sampling, Batching, Filtering, Credential management) -> Sends to Backend (Jaeger, Prometheus).
3. No Collector (Direct): App sends directly to Backend. Rarely used in large productions due to lack of flexibility.

References:

• OTel Docs: Collector Deployment
• OTel Operator Patterns

5. Semantic Conventions (Standardization)

Domain: OpenTelemetry API and SDK

OTel defines how attributes are named to ensure consistency across systems. Backends rely on this standard to render charts automatically.

• Resource Attributes (Immutable): Describes "What" is producing the telemetry.
  • Example: service.name, service.version, k8s.pod.name, cloud.region.
• Span Attributes (Dynamic): Describes "What action" is happening.
  • HTTP: http.method (GET), http.status_code (200), http.route (/api/v1/users).
  • Database: db.system (mysql), db.statement (SELECT * FROM users).
  • Note: From OTel v1.20+, some old conventions (like http.method) are gradually moving to http.request.method. Need to update according to the latest version.

References:

• OTel Docs: Semantic Conventions
• Existing Registry

6. Telemetry Signal Status

Domain: Fundamentals of Observability

Not everything in OTel is "Production Ready" (Stable). The exam may ask about the status of signals to know the reliability level when using them.

• Tracing: Stable. Mature and widely supported.
• Metrics: Stable. Fully featured to replace Prometheus.
• Logs: Stable (as of 2024). Logs Bridge API, SDK, and OTLP are stable.
• Profiling: Development. The profiling signal was accepted into OTel in 2024, with initial support being developed. Not eBPF-specific - OTel profiling is format-agnostic.

References:

• OTel Feature Status

7. SDK Mechanics: Processors & Exporters

Domain: The OpenTelemetry API and SDK (SDK Pipelines)

Just knowing "how to send data" is not enough; the exam asks how data flows inside the application before going out.

• Span Processors: Decide when spans are sent.
  • SimpleSpanProcessor: Sends immediately when span ends (1-1). Use only for development/debugging. Using for prod will severely slow down the app.
  • BatchSpanProcessor: Batches spans and sends periodically or when buffer is full. Mandatory for Production to optimize performance.
• Exporters: Interfaces responsible for sending data out (OTLP, Zipkin, Console).
  • Timeout: Appropriate timeouts need to be configured to avoid hanging the app if the backend (Collector) is slow.

References:

• OTel Docs: Trace SDK
• Java SDK Examples

8. Collector Scaling & Data Transformation

Domain: The OpenTelemetry Collector (Scaling, Transforming Data)

Deploying a single Collector is easy, but scaling a Collector cluster to handle millions of spans per second is a different challenge.

• Load Balancing: When running Gateway mode with multiple replicas, a Load Balancer is needed in front (like Nginx/K8s Service) to distribute trace load to collectors.
• Trace ID Awareness: With Tail Sampling, all spans of the same Trace ID must arrive at the same Collector instance. Need to use Load Balancing Exporter with hash ring (based on TraceID) at the Agent layer to push to the right place.
• Transform Processor (OTTL) - OpenTelemetry Transformation Language
  • Example: Delete sensitive attributes (set(attributes["password"], "****")), rename metrics, or filter garbage logs.

References:

• Collector Scaling
• Load Balancing Exporter
• Transform Processor (OTTL)

9. Debugging & Observability of the Pipeline

Domain: Maintaining and Debugging Observability Pipelines

How do you monitor the monitor (the OTel Collector) itself?

• Extensions: Auxiliary components that do not process telemetry data but help manage the Collector.
  • health_check: Endpoint /health for K8s liveness/readiness probe.
  • pprof: CPU/RAM Profiling of the Collector (to debug when Collector consumes too much RAM).
  • zpages: Simple web interface displaying real-time status of receiver/exporter (received/sent counts, errors).
• Self-Monitoring: Collector exposes its own metrics (usually on port 8888) for Prometheus to scrape (e.g., otelcol_process_uptime, otelcol_receiver_refused_spans).

References:

• Collector Troubleshooting
• Management (Extensions)

10. Handling Backpressure & Reliability

Domain: Maintaining and Debugging Observability Pipelines (Error Handling)

When the backend (Jaeger/Elasticsearch) is dead or overloaded, what does the Collector do?

• Memory Limiter Processor: Mandatory and must be placed at the beginning of the pipeline (right after receiver). It prevents Collector OOM (Out of Memory) crash by dropping data or refusing new data when RAM hits the threshold.
• Batch Processor: Helps compress and bundle data to reduce network request count.
• Retry Mechanism: Exporters usually have retry mechanisms (with backoff policy) when sending fails. However, if using QueuedRetry (persistent queue), file storage config needs attention.

References:

• Memory Limiter Processor
• Recommended Processors Config

11. Schema Management

Domain: Maintaining and Debugging Observability Pipelines (Schema Management)

When Semantic Conventions change (e.g., rename http.method -> http.request.method), how to ensure the system doesn't break?

• Schema URL: Each Resource or Scope in OTel data has an accompanying schema_url, pointing to the version of Semantic Convention it follows (e.g., https://opentelemetry.io/schemas/1.21.0).
• Schema Transformation: Helps convert data from old schema to new (or vice versa) to be compatible with old backends or dashboards.

References:

• Telemetry Schemas

12. MeterProvider and Metric Exporter

• MeterProvider: The entry point for the Metrics API. It provides Meter instances, which are used to create metric instruments (Counter, Histogram, etc.).

• Metric Exporter: Component responsible for sending aggregated metric data to backends. Common exporters: OTLP, Prometheus, Console.

• Flow: MeterProvider → Meter → Instruments → MetricReader → MetricExporter → Backend

This concept is required to know! xD (You can guess the reason!)

13. API vs SDK Distinction

• API: Defines interfaces for instrumentation (creating spans, metrics). Library authors use API only - zero dependencies, safe to include.

• SDK: Implements the API. Provides configuration, processing, and export. Application owners configure SDK at startup.

Key Point: Libraries should only depend on API. Applications configure SDK.

14. Instrumentation Scope

Each telemetry source is identified by an Instrumentation Scope: - name: Instrumentation library name (e.g., @opentelemetry/instrumentation-http) - version: Library version - schema_url: Semantic convention version

This helps identify which library generated which telemetry.

15. Collector Config Structure (Order matters!)

extensions:    # Health check, zpages, auth
receivers:     # Data ingestion (OTLP, Jaeger, Prometheus)
processors:    # Data transformation (batch, filter, transform)
exporters:     # Data output (OTLP, Jaeger, Prometheus)
connectors:    # Pipeline-to-pipeline (spanmetrics)
service:
  extensions: [...]
  pipelines:
    traces:
      receivers: [...]
      processors: [...]  # Order matters! memory_limiter first, batch last
      exporters: [...]

Honest recommend

• Before taking mock exam: read all pages about 4-5 times. I know it takes a lot of time, but it is my recommendation, since I don't want to write another 1000+ lines in a single article xD
• And yeah, the exam OTCA is about concept, how component work or their relationship. Not much detail for configuration.

https://opentelemetry.io/docs/what-is-opentelemetry/

My Secret Weapon: Mock Exam

After absorbing all the concepts above, there's one more crucial step before you're truly exam-ready: practice with mock exams.

I used this Udemy course to prepare, and it made a real difference:

Complete OpenTelemetry Certified Associate (OTCA) Exam Prep

Final Wrap

• I passed the OTCA exam with a score of 77/100 — not a perfect score, but enough to get the job done.
• This article contains everything I wish I had when I started preparing.
• If you've made it this far, you're already ahead of most candidates. Now go schedule that exam and get certified!

Good luck bro!
