Prerequisite

• Basic knowledge of GitOps
• ArgoCD setup installation, ArgoCD Rollout

Section needs to understand

What is the purpose of the argocd-repo-server component?

Short answer: git clone and generate manifests

The argocd-repo-server has two main responsibilities:

• Repository Management: It clones and maintains a local cache of the Git repository.
• Manifest Generation: It renders the application manifests (YAML) from the source code using configuration management tools (e.g., Helm, Kustomize).

So in context Rendered Manifests Pattern (I generated manifest and push to GitOps repo) how it will work?.

1. Clone/Fetch
2. Detect & Parse: without Chart.yaml or kustomization.yaml, repo-server will trigger logic of Directory Application.
3. Return Manifests: repo-server will read content of manifests then return it to Application Controller (argocd-application-controller)

Document here: https://argo-cd.readthedocs.io/en/stable/user-guide/directory/

What is Argo Workflows?

Wow, I never heard about Argo Workflows before, only 2 component that I know before were ArgoCD and Argo Rollouts. So let get into work!

Argo Workflows is an open source container-native workflow engine for orchestrating parallel jobs on Kubernetes, native for K8S, Argo Workflows is implemented as a Kubernetes CRD.

Each step in the workflow is a container. Hmm, this seems not correct. Let me correct it:

Each step calls a template. Templates of type container/script create pods for execution, while other types (dag, steps, resource, suspend) handle orchestration without creating pods

Example: It works same as Jenkins, GitHub Actions, or GitLab CI. It does Checkout code -> Build Docker Image -> Run Test -> Push into Registry.

Document: https://argoproj.github.io/workflows/

How do steps in a workflow pass data to each other?

The section above is for this question!

Short answer: There are 2 types of data you can pass to each other

• Parameters (Variable, string)
• Artifacts (File, Folder)

So let take an example from here for better understanding:

https://argo-workflows.readthedocs.io/en/latest/walk-through/output-parameters/

apiVersion: argoproj.io/v1alpha1
kind: Workflow
metadata:
  generateName: output-parameter-
spec:
  entrypoint: output-parameter
  templates:
  - name: output-parameter
    steps:
    - - name: generate-parameter
        template: hello-world-to-file
    - - name: consume-parameter
        template: print-message
        arguments:
          parameters:
          # Pass the hello-param output from the generate-parameter step as the message input to print-message
          - name: message
            value: "{{steps.generate-parameter.outputs.parameters.hello-param}}"

  - name: hello-world-to-file
    container:
      image: busybox
      command: [sh, -c]
      args: ["echo -n hello world > /tmp/hello_world.txt"]  # generate the content of hello_world.txt
    outputs:
      parameters:
      - name: hello-param  # name of output parameter
        valueFrom:
          path: /tmp/hello_world.txt # set the value of hello-param to the contents of this hello-world.txt

  - name: print-message
    inputs:
      parameters:
      - name: message
    container:
      image: busybox
      command: [echo]
      args: ["{{inputs.parameters.message}}"]

First, look at hello-world-to-file template

• Action: Container run command echo -n hello world > /tmp/hello_world.txt
• After container finished, but not deleted, Argo Agent will read content of file /tmp/hello_world.txt then set that content into variable called hello-param. And look at that valueFrom is where it's data comes from!

Second, pass data, look at main template output-parameter in steps, this is where it passes data from outputs to steps

    - - name: consume-parameter
        template: print-message
        arguments:
          parameters:
          # Pass the hello-param output from the generate-parameter step as the message input to print-message
          - name: message
            value: "{{steps.generate-parameter.outputs.parameters.hello-param}}"

In this step call the template print-message, but it said I need to load data for the fucking variable message.

Syntax: {{steps.<step_name>.outputs.parameters.<variable_name>}}

• It pointed to step generate-parameter
• It gets the hello-param
• Then it put into input message of current step

Third, look at template print-message

Define: I need the fucking input called message to run!

inputs:
  parameters:
  - name: message

Usage:

args: ["{{inputs.parameters.message}}"]

• At this moment: {{inputs.parameters.message}} will be replaced with "hello world"
• Command will be echo "hello world"

So note for the CAPA exam: Where is outputs located?

• outputs defined in template of who created that data.
• Must use valueFrom: path: ... to tell Argo Workflow read from which file.

Reference?

• In steps, when we want to get data, we must use prefix steps. Example: steps.generate-parameter...
• If you write with word steps, ex: outputs.parameters it will be resulted as invalid syntax.

Almost 90 lines for simple explanation xD. But its worth!

What is the primary CRD for Argo Workflows?

As for the name and what we have go through, it is Workflow.

In Argo Workflows, what is a 'Suspend' template?

We can simply understand it as Pause of Workflow!

Document: https://argo-workflows.readthedocs.io/en/latest/walk-through/suspending/

The suspend template is a template type that will suspend the workflow for a `duration` or `indefinitely`.

For exam, I think it can be best remember with Suspend = Manual Approval

Let's learn about Argo Events

This is 4th project from Argo Project which I have no idea before xD

Argo Events is an event-based dependency manager for Kubernetes which helps you define multiple dependencies from a variety of event sources like webhook, s3, schedules, streams etc. and trigger Kubernetes objects after successful event dependencies resolution

So for exam note:

• Argo Events = Event-Driven / Dependency Manager.
• Source = where events raised (GitHub, Slack, SNS, Cron...)
• Trigger = Trigger something, commonly trigger Argo Workflows
• Sensor = Dependency Manager. Always have 2 parts: dependencies and triggers

So this is important section, I will try to understand via real example:

Source: https://github.com/argoproj/argo-events/blob/master/examples/sensors/redis.yaml

Purpose: This Sensor acts as a bridge between Redis and Argo Workflows.

• Dependency: It listens for the specific event from the Redis EventSource defined in dependencies.

{
  "header": { "timestamp": "123456" },
  "body": {
    "user": "admin",
    "message": "Hello World"  <-- I want to get this!!!
  }
}

• Parameterization: It dynamically extracts the body.message from the Redis event payload (src) and injects it into the Workflow's arguments (dest). You can understand it as concept "Find & Replace" data from event into Workflow

parameters:
        - src:
            dependencyName: test-dep   # 1. Get from where?
            dataKey: body.message      # 2. Get what?
          dest: spec.arguments.parameters.0.value  # 3. Put where?

• Trigger: Once the dependency is met, it creates the Argo Workflow resource in the cluster.

Tell me about AnalysisRun in Argo Rollouts

AnalysisRun is the initialization of AnalysisTemplate. It is responsible for querying the metrics provider and deciding whether the deployment should continue or be rolled back.

What is Sync Phases and Waves in ArgoCD?

Document: https://argo-cd.readthedocs.io/en/stable/user-guide/sync-waves/#sync-phases-and-waves

Sync Waves (The "Order"):

• Purpose: Controls the sequence of deployment between resources.
• Mechanism: Uses integers (e.g., sync-wave: "1"). Lower numbers apply first. (Accepted number lower than 0 also xD)
• Key Rule: Argo CD waits for the current wave to be Healthy before starting the next wave.
• Use Case: Start Database (Wave 0) -> Start Backend (Wave 1).

Sync Phases (The "Timing/Hooks"):

• Purpose: Controls the lifecycle steps of the synchronization.
• Mechanism: Three main buckets: PreSync -> Sync (Main) -> PostSync.
• Key Rule: If a hook (like PreSync) fails, the sync stops.
• Use Case: Run DB Migration Job (PreSync) -> Deploy App (Sync) -> Send Slack Notification (PostSync).

Summary Relationship:

Phases define the Strategy (When), and Waves define the Order (Who goes first) within those phases. (Note: You can even have Waves inside a Phase, e.g., multiple PreSync jobs running in order).

Example with sync waves

apiVersion: apps/v1
kind: Deployment
metadata:
  name: my-backend
  annotations:
    argocd.argoproj.io/sync-wave: "1"  # <--- wait for wave 0 finished then run

Example with sync phases: database migration

• PreSync: Database Migration Job

apiVersion: batch/v1
kind: Job
metadata:
  name: db-migration-job
  annotations:
    # This is how phase definition
    argocd.argoproj.io/hook: PreSync

    # important for CAPA: delete this fucking job job after run to avoid trash
    argocd.argoproj.io/hook-delete-policy: HookSucceeded
spec:
  template:
    spec:
      containers:
      - name: migrate
        image: my-app:v2
        command: ["./migrate-db.sh"]
      restartPolicy: Never

• Sync (Main): Application Deployment

apiVersion: apps/v1
kind: Deployment
metadata:
  name: my-backend-app
  # Without annotation hook, default is Sync phase
spec:
  replicas: 3
  template:
    spec:
      containers:
      - name: app
        image: my-app:v2 # new code need new DB structure

• PostSync: Notification Job This only run after second step is Healthy

apiVersion: batch/v1
kind: Job
metadata:
  name: slack-notification
  annotations:
    argocd.argoproj.io/hook: PostSync
    argocd.argoproj.io/hook-delete-policy: HookSucceeded
spec:
  template:
    spec:
      containers:
      - name: slack-curl
        image: curlimages/curl
        command: ["curl", "-X", "POST", "https://hooks.slack.com/...", "-d", "'Deploy Success!'"]
      restartPolicy: Never

CAPA exam tip: remember annotation argocd.argoproj.io/hook-delete-policy. Without this line, next deploy will error because duplicated job name. So there are some policies for hook-delete-policy

• HookSucceeded: Delete after success (Recommend)
• BeforeHookCreation: Delete old before create new one
• HookFailed: Delete hook if fails

Argo Workflows - DAG templates

As an alternative to specifying sequences of steps, you can define a workflow as a directed-acyclic graph (DAG) by specifying the dependencies of each task. DAGs can be simpler to maintain for complex workflows and allow for maximum parallelism when running tasks.

Document: https://argo-workflows.readthedocs.io/en/latest/walk-through/dag/

Which CLI tool is used for Argo Rollouts?

Document: https://argo-rollouts.readthedocs.io/en/stable/features/kubectl-plugin/

Answer: kubectl argo rollouts

What is the 'Executor' in Argo Workflows?

Document: https://argo-workflows.readthedocs.io/en/latest/workflow-executors/

The executor is a process that conforms to a specific interface that allows Argo to perform certain actions like capturing artifacts, logs, etc... Emissary is the default executor (From version 3.3+, before was Docker!)

Which CLI tool is used for Argo Workflows?

Answer: argo Document: https://argo-workflows.readthedocs.io/en/latest/walk-through/argo-cli/

Which command deletes all completed workflows?

argo delete --completed

Related Document: https://github.com/argoproj/argo-workflows/blob/main/docs/cli/argo_delete.md

How do you run a script (e.g., Python) directly inside a workflow step without building a custom image?

Short Answer: Use the script template type instead of container

Example:

apiVersion: argoproj.io/v1alpha1
kind: Workflow
metadata:
  generateName: scripts-python-
spec:
  entrypoint: python-script-example
  templates:
  - name: python-script-example
    steps:
    - - name: generate
        template: gen-random-int

  - name: gen-random-int
    script:    # <--- use 'script' instead of 'container'
      image: python:alpine3.6
      command: [python]
      source: |
        import random
        i = random.randint(1, 100)
        print(i)

Document where I copy code xD:

https://argo-workflows.readthedocs.io/en/latest/walk-through/scripts-and-results/

Which annotation allows you to delete a resource from the cluster but keep it in Git without Argo CD recreating it immediately?

Resource Exclusion or annotation

argocd.argoproj.io/compare-options: IgnoreExtraneous

Document: https://argo-cd.readthedocs.io/en/stable/user-guide/compare-options/

What is argocd-image-updater?

Another "WoW, what is this?"

So basically it is a tool to automatically update the container images of Kubernetes workloads that are managed by Argo CD as the name of it "ArgoCD image updater" xD

Document: https://argocd-image-updater.readthedocs.io/en/stable/

Example:

apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  annotations:
    # 1. Enable feature for image 'my-image'
    argocd-image-updater.argoproj.io/image-list: my-image=my-registry/my-app

    # 2. Select strategy to update (ex: only update latest version)
    # semver: update to highest allowed version according to given image constraint
    # More strategy: https://argocd-image-updater.readthedocs.io/en/stable/#features
    argocd-image-updater.argoproj.io/my-image.update-strategy: semver

    # 3. Write back into Git (Fuck yeah)
    argocd-image-updater.argoproj.io/write-back-method: git
spec:
  # ...

Note for CAPA Exam:

• Git Write-back: it commits into gitops repo (create new commit with message like: "Update image to v1.1")
• Argo CD API (Imperative): It updates the Application resource directly in the cluster via Argo CD API, without modifying Git.

ArgoCD Notifications

Argo CD Notifications is a controller that continuously monitors Argo CD applications and sends alerts to external services (like Slack, Email, Telegram, Discord, or Webhooks) when specific events occur.

It relies on three main concepts:

1. Triggers: Defines when to send a notification (e.g., on-sync-failed, on-health-degraded).
2. Templates: Defines what to say (the message content/format).
3. Services: Defines where to send it (the destination credentials).

Document: Argo CD Docs - Notifications

What are Application URLs (External URLs)?

This feature allows you to access your deployed application directly from the Argo CD UI (via a small "launch" icon on the Service or Ingress resource).

How it works:

• Auto-Discovery: By default, Argo CD tries to automatically find the URL by looking at the host field in your Ingress.
• Manual Configuration: If auto-discovery fails (or if you use NodePort), you can manually specify the URL by adding this specific annotation to your Ingress, Service, or Route:

    link.argocd.argoproj.io/external-link: http://my-app.example.com

Document: External URL

Argo Workflows: Artifacts - Passing Files/Folders between Steps

Different from Parameters (string), Artifacts used to pass files/folders between steps.

- name: create-file
  container:
    image: alpine:latest
    command: [sh, -c]
    args: ["echo 'hello' > /tmp/message.txt"]
  outputs:
    artifacts:
    - name: message-file
      path: /tmp/message.txt      # Argo grabs this file

- name: print-file
  inputs:
    artifacts:
    - name: message-file          # Same name to receive
      path: /tmp/received.txt     # Where to put in this container
  container:
    image: alpine:latest
    command: [cat, /tmp/received.txt]

CAPA exam note:

• Parameters = small strings, use {{steps.xxx.outputs.parameters.yyy}}
• Artifacts = files/folders, stored in S3/GCS/Minio (configurable)
• Artifact storage options: s3, gcs, azure, oss, hdfs, artifactory

Argo Workflows: WorkflowTemplate vs ClusterWorkflowTemplate

Same concept as ConfigMap vs ClusterRole!

• WorkflowTemplate: Namespaced, only usable within same namespace
• ClusterWorkflowTemplate: Cluster-wide, usable from any namespace

How to reference:

steps:
- - name: call-template
    templateRef:
      name: my-template           # Template name
      template: main              # Which template inside
      # clusterScope: true        # Add this for ClusterWorkflowTemplate

Argo Workflows: CronWorkflow - Scheduled Workflows

apiVersion: argoproj.io/v1alpha1
kind: CronWorkflow
metadata:
  name: nightly-backup
spec:
  schedule: "0 2 * * *"           # Cron syntax
  timezone: "Asia/Ho_Chi_Minh"
  concurrencyPolicy: Replace      # What if previous still running?
  workflowSpec:
    entrypoint: backup-job
    templates:
    - name: backup-job
      container:
        image: backup-tool:latest

concurrencyPolicy options (CAPA exam!):

• Allow: Run concurrent (default)
• Forbid: Skip if previous still running
• Replace: Kill previous, start new

Argo Workflows: Retry Strategy & Timeout

templates:
- name: flaky-step
  retryStrategy:
    limit: 3
    retryPolicy: "OnFailure"      # Only retry on non-zero exit
    backoff:
      duration: "5s"
      factor: 2                   # 5s -> 10s -> 20s
  container:
    image: my-app

retryPolicy options:

• Always: Any failure
• OnFailure: Non-zero exit code only
• OnError: Argo errors only (not container failures)
• OnTransientError: Network issues

Timeout:

spec:
  activeDeadlineSeconds: 3600     # Workflow level: 1 hour max
  templates:
  - name: task
    activeDeadlineSeconds: 600    # Template level: 10 min max

Argo Workflows: Parallelism - withItems, withParam, withSequence

# Static list
- name: process
  template: process-file
  withItems: ["file1.csv", "file2.csv", "file3.csv"]

# Dynamic list from previous step (JSON array)
- name: process
  template: process-file
  withParam: "{{steps.get-files.outputs.result}}"

# Generate sequence
- name: process
  template: work
  withSequence:
    count: 5          # 0,1,2,3,4
    # OR start: 1, end: 10

CAPA exam note:

• withItems: Static list in YAML
• withParam: Dynamic JSON array from previous step
• withSequence: Generate numbers

Argo Workflows: Exit Handler - Finally block

spec:
  entrypoint: main
  onExit: cleanup-handler         # Always run at the end!

  templates:
  - name: cleanup-handler
    container:
      image: alpine
      command: [echo, "Cleaning up..."]

CAPA exam note: onExit runs regardless of success/failure - like finally in code.

ArgoCD: Application Source Types

ArgoCD supports multiple source types. When no Chart.yaml or kustomization.yaml found, it defaults to Directory (plain YAML).

spec:
  source:
    repoURL: https://github.com/my-org/my-repo
    targetRevision: HEAD
    path: manifests/

    # For Helm
    helm:
      valueFiles:
        - values-prod.yaml
      parameters:
        - name: replicas
          value: "3"

    # For Kustomize
    kustomize:
      namePrefix: prod-
      images:
        - my-app:v2.0

CAPA exam note: Know the difference between helm.values (inline) vs helm.valueFiles (from file)

ArgoCD: Sync Options

Common sync options via annotation or Application spec:

metadata:
  annotations:
    argocd.argoproj.io/sync-options: |
      Prune=true
      SelfHeal=true
      CreateNamespace=true

CAPA exam note: SelfHeal + Prune = fully automated GitOps (no manual intervention)

ArgoCD: Health Status vs Sync Status

Two different things!

• Sync Status: Is cluster state = Git state? (Synced, OutOfSync)
• Health Status: Is application actually working? (Healthy, Progressing, Degraded, Suspended)

Example: App can be Synced but Degraded (manifests applied but pods crashing)

CAPA exam note: Refresh = check, Sync = apply

ArgoCD: AppProject - RBAC for Applications

apiVersion: argoproj.io/v1alpha1
kind: AppProject
metadata:
  name: production
spec:
  description: Production apps only

  # Allowed Git sources
  sourceRepos:
    - 'https://github.com/my-org/*'

  # Allowed destinations
  destinations:
    - namespace: 'prod-*'
      server: https://kubernetes.default.svc

  # Allowed/Denied resources
  clusterResourceWhitelist:
    - group: ''
      kind: Namespace
  namespaceResourceBlacklist:
    - group: ''
      kind: Secret

CAPA exam note: default project allows everything. Create custom projects to restrict source repos, destinations, and resource types.

ArgoCD: ApplicationSet - Generate Multiple Apps

Instead of creating 10 Applications manually, use ApplicationSet:

apiVersion: argoproj.io/v1alpha1
kind: ApplicationSet
metadata:
  name: my-apps
spec:
  generators:
    # List generator - static list
    - list:
        elements:
          - env: dev
            namespace: dev
          - env: prod
            namespace: prod

  template:
    metadata:
      name: 'myapp-{{env}}'
    spec:
      project: default
      source:
        repoURL: https://github.com/org/repo
        path: 'envs/{{env}}'
      destination:
        server: https://kubernetes.default.svc
        namespace: '{{namespace}}'

Common generators (CAPA exam!):

• list: Static list of values
• clusters: Generate app per cluster
• git: Generate from directories/files in Git
• matrix: Combine multiple generators

CAPA exam note: App of Apps = manual setup, ApplicationSet = dynamic/automated generation

Argo Rollouts: AnalysisTemplate vs ClusterAnalysisTemplate

Same pattern again - namespaced vs cluster-wide:

apiVersion: argoproj.io/v1alpha1
kind: AnalysisTemplate          # or ClusterAnalysisTemplate
metadata:
  name: success-rate
spec:
  args:
    - name: service-name
  metrics:
    - name: success-rate
      interval: 1m
      count: 3                   # Run 3 times
      successCondition: result[0] >= 0.95
      failureLimit: 1            # Fail after 1 bad result
      provider:
        prometheus:
          address: http://prometheus:9090
          query: |
            sum(rate(http_requests_total{status=~"2.*", app="{{args.service-name}}"}[5m]))
            /
            sum(rate(http_requests_total{app="{{args.service-name}}"}[5m]))

CAPA exam note:

• successCondition: Expression must be true to pass
• failureLimit: How many failures before rollback
• count: How many times to run the measurement
• interval: Time between measurements

Argo Events: EventBus - Transport Layer

EventBus is the backbone that connects EventSources to Sensors. Think of it as message queue.

apiVersion: argoproj.io/v1alpha1
kind: EventBus
metadata:
  name: default
spec:
  # Option 1: NATS (default, simplest)
  nats:
    native:
      replicas: 3
      auth: token

  # Option 2: Jetstream (NATS with persistence)
  # jetstream:
  #   version: latest

  # Option 3: Kafka
  # kafka:
  #   url: kafka-broker:9092

CAPA exam note:

• EventBus must exist before EventSource and Sensor work
• Default name is default - if you name it differently, must reference in EventSource/Sensor
• NATS = simple, Jetstream = persistent, Kafka = enterprise scale

Argo Events: Common EventSource Types

apiVersion: argoproj.io/v1alpha1
kind: EventSource
metadata:
  name: my-sources
spec:
  # Webhook - receive HTTP POST
  webhook:
    github-webhook:
      port: "12000"
      endpoint: /github
      method: POST

  # Calendar/Cron - scheduled events
  calendar:
    daily-trigger:
      schedule: "0 9 * * *"      # 9 AM daily
      timezone: "Asia/Ho_Chi_Minh"

  # AWS SNS
  sns:
    my-sns:
      topicArn: arn:aws:sns:us-east-1:123456789:my-topic
      region: us-east-1

  # AWS SQS
  sqs:
    my-sqs:
      queue: my-queue
      region: us-east-1

  # GitHub (native integration)
  github:
    repo-events:
      repositories:
        - owner: my-org
          names: [my-repo]
      events: [push, pull_request]
      webhook:
        endpoint: /github
        port: "13000"

CAPA exam note: One EventSource can have multiple sources of same or different types.

Argo Events: Sensor - Trigger Conditions & Filters

Filter events before triggering:

apiVersion: argoproj.io/v1alpha1
kind: Sensor
metadata:
  name: my-sensor
spec:
  dependencies:
    - name: github-dep
      eventSourceName: my-sources
      eventName: github-webhook
      filters:
        data:
          # Only trigger for 'main' branch
          - path: body.ref
            type: string
            value:
              - "refs/heads/main"

        # Time filter - only during work hours
        time:
          start: "09:00:00"
          stop: "18:00:00"

  triggers:
    - template:
        name: run-workflow
        k8s:
          operation: create
          source:
            resource:
              apiVersion: argoproj.io/v1alpha1
              kind: Workflow
              metadata:
                generateName: ci-build-
              spec:
                entrypoint: build
                # ... workflow spec

Filter types (CAPA exam!):

• data: Filter by event payload content
• time: Filter by time of day
• context: Filter by event metadata
• exprs: CEL expressions for complex logic

Argo Events: Multiple Dependencies - AND/OR Logic

spec:
  dependencies:
    - name: webhook-dep
      eventSourceName: webhook-source
      eventName: my-webhook
    - name: calendar-dep
      eventSourceName: calendar-source
      eventName: daily

  triggers:
    - template:
        name: my-trigger
        conditions: "webhook-dep && calendar-dep"  # AND - both must fire
        # conditions: "webhook-dep || calendar-dep"  # OR - either one

CAPA exam note: Default behavior (no conditions) = AND logic (all dependencies must be satisfied)

Argo Events: Trigger Types

Sensor can trigger different resources:

triggers:
  # 1. Create Argo Workflow
  - template:
      name: workflow-trigger
      k8s:
        operation: create
        source:
          resource:
            apiVersion: argoproj.io/v1alpha1
            kind: Workflow

  # 2. Create any K8s resource
  - template:
      name: job-trigger
      k8s:
        operation: create
        source:
          resource:
            apiVersion: batch/v1
            kind: Job

  # 3. HTTP request (webhook out)
  - template:
      name: http-trigger
      http:
        url: https://api.example.com/webhook
        method: POST

  # 4. AWS Lambda
  - template:
      name: lambda-trigger
      awsLambda:
        functionName: my-function
        region: us-east-1

CAPA exam note: Most common trigger = Argo Workflow, but can trigger any K8s resource or external services.

Argo Events: Complete Flow Diagram

┌─────────────┐     ┌──────────┐     ┌─────────┐     ┌──────────┐
│ EventSource │ --> │ EventBus │ --> │ Sensor  │ --> │ Workflow │
│ (webhook,   │     │ (NATS/   │     │ (filter │     │ (or any  │
│  calendar,  │     │  Kafka)  │     │  +match)│     │  K8s res)│
│  SNS, etc)  │     │          │     │         │     │          │
└─────────────┘     └──────────┘     └─────────┘     └──────────┘

CAPA exam note summary:

• EventSource: WHERE events come from
• EventBus: HOW events are transported
• Sensor: WHAT to do when events match (filter + trigger)

My secret weapon: Mock Exam

Udemy practice test:

https://www.udemy.com/course/complete-certified-argo-project-associate-capa-exam-prep/

Exam note:

• Exam duration: 90 minutes
• Exam questions: 60 questions
• The exam required 75/100 to pass, and I scored 80/100!
• You should memorize and understand everything in kind: Application
• Another you should care about is ignoreDifferences

Good luck with the exam
